Plasser & Theurer/Framafer  108-32 U

Well maintained 108-32 with integrated Stabilizing and sweeping unit.

Year of manufacturing:

Pre-owned
2013

Type of machine:

Designation

specifications

Plasser & Theurer 108-32 U – High Performance Plain LINE TAMPER with integrateed STABILIZING AND SWEEPING UNIT

The Plasser & Theurer 108‑32 U is a versatile plain‑line tamping machine equipped with a 32‑tine tamping unit, engineered to deliver outstanding track geometry correction and long‑lasting ballast stability. This model stands out for its ability to combine multiple work functions in a single, efficient machine.

Key Highlights:

  • 32‑Tine Tamping Aggregate: Ensures precise and powerful compaction for high‑quality plain‑line tamping.
  • Integrated Stabilizing Unit: Enhances track stability immediately after tamping, reducing the need for additional machinery.
  • Built‑In Sweeping Unit: Allows for clean finishing of the worksite, streamlining operations and improving track appearance.
  • Modern Control Systems: Fully equipped for deployment on the French market, meeting all relevant operational and safety requirements.
  • Major Component Upgrades:
    • New engine (2025)
    • Overhauled tamping unit (2024)
    • Valid technical certification (2024)
  • Proven in Operation: Currently working successfully in France.

This machine represents a rare opportunity to acquire a relatively young, highly capable, multi‑function tamping unit—ideal for operators seeking maximum productivity.


Year of manufacture

2013

Plasser & Theurer Machine Nr

3538

Track gauge

 1435mm

EVN Number

99 87 9 122 531-6

Length

33.590mm

Width

3.000mm

Height (over top of rail)

3.330mm

Engine

Deutz TCD2015 V8, 370kW

Weight (unloaded)

~84 t

Driving speed

100 km/h

Maximum pulling speed

100 km/h

CE-comformity

EU
